Gillette SP-1500-3-2 | 150kW 3-Phase Natural Gas Generator Set

Key Features:

• 150kW / 188kVA standby output at 120/208V, three-phase, 60Hz, 0.80 power factor
• PSI 8.8LTCAC 4-cycle turbocharged and charge-air-cooled industrial powertrain engine with 10.1:1 compression ratio and 259HP output at 1,800 RPM
• Electronic governor with throttle body actuator for precise isochronous frequency regulation
• Stamford UCI274G1 brushless alternator, 12-lead reconnectable, single bearing, 120°C temperature rise, Class H insulation
• Solid-state frequency-compensated automatic voltage regulation with plus or minus 0.5% regulation from no load to full load
• Deep Sea 7420 digital controller with backlit LCD display, stop/manual/auto modes, power monitoring, event logging and hour meter
• Radiator-cooled system with jacket water heater included
• Built-in battery charger, battery rack, cables, charging alternator and space heaters
• Fuel shut-off solenoid, air-fuel ratio controller and oxidation catalyst included
• Mounted exhaust silencer included
• Heavy-duty circuit breaker rated at 100% to 125% capacity, standard on all units
• Available in Open Frame or Level 2 aluminum sound-attenuated enclosure
• Meets NFPA-110 Level 1 requirements with applicable accessories
• UL-1446 and UL-2200 certified
• USA prototype built, factory built and 100% load tested

Applications:

• Healthcare facilities and hospitals
• Hotels and office buildings
• Medical centers and critical care institutions
• Wastewater and utility facilities
• Industrial and commercial standby power

Fuel: Natural Gas (LP rated at 130kW, consult spec sheet)

Warranty: 24 months / 1,000 hours (alternator) | 12 months / 2,000 hours (engine) | 1 year limited on control system components
