Deep Sea Electronics DSE7310 MKII | Auto Start Control Module with Wiring Harness & Enclosure
- DSE7310 MKII auto start generator control module — includes wiring harness and enclosure
- Compatible with single diesel or gas generator sets, both electronic (CAN) and non-electronic engines
- Dual Core processor with 4-line backlit LCD display, illuminated LEDs, and data logging
- USB, RS232, RS485 communication ports and DSENet® expansion terminals
- Fully configurable via DSE Configuration Suite PC software
- New-generation auto start genset control module with Dual Core main processor and extended memory for faster processing and enhanced functionality
- Suitable for a wide variety of single-unit diesel or gas generator set applications
- Compatible with both electronic (CAN bus) and non-electronic (magnetic pick-up or alternator sensing) engines
- 4-line backlit LCD display with 5-key menu navigation showing warnings, shutdown events, and engine/generator status in real time
- Multiple configurable display languages with customizable power-up text and images
- Heated display variant available for cold-environment installations (operating range: -40°C to +70°C)
- Extensive data logging facility for performance tracking and maintenance history
- Internal Advanced PLC editor — enables drag-and-drop programmable logic for custom automation sequences
- Fuel monitoring and control capability — supports resistive fuel level senders, fuel pump control, and low-level alarms
- Built-in scheduler for automated start/stop cycles based on time or external trigger
- Configurable protections with protections disable feature for commissioning and testing
- Inputs: 8 configurable negative digital inputs (A–H); 2 analogue inputs (A & F) configurable as digital, 0–10V, 4–20mA, or resistive sensor; 4 analogue inputs (B, C, D & E) configurable as digital or resistive sensor
- Outputs: Fuel (A) and Start (B) outputs at 15A DC; Outputs C & D at 8A AC volt-free; 6 auxiliary outputs (E–J) at 2A DC
- DSENet® terminals for system expansion (remote annunciators, I/O modules, battery charger monitoring)
- RS232 port (Modbus RTU) for short-range communication or modem/GSM connection with SMS alert capability
- RS485 port (Modbus RTU) for integration with building management systems, PLCs, and SCADA
- USB port for direct PC configuration and firmware updates
- IP65 rated from the front panel when properly installed with gasket in a control panel
- Includes pre-wired wiring harness and enclosure for simplified installation
Applications:
- Standby and prime power diesel and gas generator sets
- Industrial and commercial generator control panel retrofits and upgrades
- Remote monitoring and automated generator start/stop applications
- Fuel management and scheduled generator exercise programs
- Integration with building management and SCADA systems
Electrical Specifications:
- DC Supply Voltage: 8V to 35V continuous (5V for up to 1 minute)
- Cranking Dropout Survival: 0V for 100ms (no internal battery required)
- Max Operating Current: 510mA @ 12V / 240mA @ 24V
- Max Standby Current: 330mA @ 12V / 160mA @ 24V
- Generator Voltage Range: 15V to 415V AC (Ph-N) / 25V to 719V AC (Ph-Ph)
- Frequency Range: 3.5 Hz to 75 Hz
- Magnetic Pickup Input: ±0.5V to 70V / up to 10,000 Hz
- Charge Fail/Excitation Range: 0V to 35V
- Operating Temperature: -30°C to +70°C (-22°F to +158°F)
- Storage Temperature: -40°C to +85°C (-40°F to +185°F)
- Front Panel Protection: IP65 (with gasket installed)
- Overall Dimensions: 245mm x 184mm x 51mm (9.6″ x 7.2″ x 2.0″)
- Panel Cutout: 220mm x 160mm (8.7″ x 6.3″)
- Max Panel Thickness: 8mm (0.3″)
- Weight: 0.88 kg
