Gillette SP-5000-3-4N2 | 500kW 3-Phase Natural Gas Generator Set

Key Features:

• 500kW / 625kVA standby output at 277/480V, three-phase, 60Hz, 0.80 power factor
• PSI 21.9L turbocharged and charge-air-cooled natural gas engine at 1,800 RPM with 10.5:1 compression ratio
• Electronic governor with throttle body actuator for precise isochronous frequency regulation
• Stamford HCI53D1 brushless alternator, 12-lead reconnectable, single bearing, AREP excitation, Class H insulation
• Solid-state frequency-compensated automatic voltage regulation with plus or minus 0.5% regulation from no load to full load
• Total harmonic distortion at 3% maximum (MIL-STD 705B)
• Deep Sea 7420 digital controller with full-text LCD display, stop/manual/auto modes, power monitoring, event logging and hour meter
• 800A heavy-duty circuit breaker standard
• Charging alternator, coolant level sensor and battery charger included
• Fuel shut-off solenoid, air-fuel ratio controller, oxidation catalyst and mounted exhaust silencer included
• Sound-attenuated factory enclosure (186″ L x 72″ W x 94″ H, 11,475 lbs)
• Available in Open Frame or Level 2 aluminum sound-attenuated enclosure
• Meets NFPA-110 Level 1 requirements with applicable accessories
• UL-1446 and UL-2200 certified
• USA prototype built, factory built and 100% load tested

Applications:

• Large commercial and industrial standby power
• Healthcare facilities and hospitals
• Data centers and critical infrastructure
• Hotels and office complexes
• Wastewater treatment and utility facilities

Fuel: Natural Gas (LP rated at 300kW, consult spec sheet)

Warranty: 24 months / 1,000 hours (alternator) | 12 months / 2,000 hours (engine) | 1 year limited on control system components
